MAX5206ACUB+
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MAX5206ACUB+ |
|---|---|
| Manufacturer | Maxim Integrated |
| Description | 16 Bit Digital to Analog Converter 1 10-uMAX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MAX5206ACUB+ Price |  |
Technical Specifications of MAX5206ACUB+
| Datasheet |  MAX5206ACUB+ datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Digital to Analog Converters (DAC) |
| Manufacturer | Maxim Integrated |
| Series | - |
| Packaging | Tube |
| Part Status | Obsolete |
| Number of Bits | 16 |
| Number of D/A Converters | 1 |
| Settling Time | 25μs (Typ) |
| Output Type | Voltage - Buffered |
| Differential Output | No |
| Data Interface | SPI |
| Reference Type | External |
| Voltage - Supply, Analog | 2.7 V ~ 3.6 V |
| Voltage - Supply, Digital | 2.7 V ~ 3.6 V |
| INL/DNL (LSB) | ±10, ±1 (Max) |
| Architecture | - |
| Operating Temperature | 0°C ~ 70°C |
| Package / Case | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) |
| Supplier Device Package | 10-uMAX |
