AD5452YRM
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | AD5452YRM |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Description | 12 Bit Digital to Analog Converter 1 8-MSOP |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| AD5452YRM Price |  |
Technical Specifications of AD5452YRM
| Datasheet |  AD5452YRM datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Digital to Analog Converters (DAC) |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Number of Bits | 12 |
| Number of D/A Converters | 1 |
| Settling Time | 110ns |
| Output Type | Current - Unbuffered |
| Differential Output | No |
| Data Interface | SPI, DSP |
| Reference Type | External |
| Voltage - Supply, Analog | 2.5 V ~ 5.5 V |
| Voltage - Supply, Digital | 2.5 V ~ 5.5 V |
| INL/DNL (LSB) | ±0.5 (Max), ±1 (Max) |
| Architecture | R-2R |
| Operating Temperature | -40°C ~ 125°C |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
| Supplier Device Package | 8-MSOP |
