AD5325BRM-REEL7
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | AD5325BRM-REEL7 |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Description | 12 Bit Digital to Analog Converter 4 10-MSOP |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| AD5325BRM-REEL7 Price |  |
Technical Specifications of AD5325BRM-REEL7
| Datasheet |  AD5325BRM-REEL7 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Digital to Analog Converters (DAC) |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Number of Bits | 12 |
| Number of D/A Converters | 4 |
| Settling Time | 10μs |
| Output Type | Voltage - Buffered |
| Differential Output | No |
| Data Interface | I2C |
| Reference Type | External |
| Voltage - Supply, Analog | 2.5 V ~ 5.5 V |
| Voltage - Supply, Digital | 2.5 V ~ 5.5 V |
| INL/DNL (LSB) | ±2, ±0.2 |
| Architecture | String DAC |
| Operating Temperature | -40°C ~ 105°C |
| Package / Case | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) |
| Supplier Device Package | 10-MSOP |
