DG2707DN-T1-E4
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | DG2707DN-T1-E4 |
|---|---|
| Manufacturer | Vishay Siliconix |
| Description | 2 Circuit IC Switch 4:1 5.5 Ohm 16-miniQFN (1.8x2.6) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| DG2707DN-T1-E4 Price |  |
Technical Specifications of DG2707DN-T1-E4
| Datasheet |  DG2707DN-T1-E4 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Vishay Siliconix |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part Status | Last Time Buy |
| Switch Circuit | SP4T |
| Multiplexer/Demultiplexer Circuit | 4:1 |
| Number of Circuits | 2 |
| On-State Resistance (Max) | 5.5 Ohm |
| Channel-to-Channel Matching (ΔRon) | 300 mOhm |
| Voltage - Supply, Single (V+) | 1.65 V ~ 4.3 V |
| Voltage - Supply, Dual (V±) | - |
| Switch Time (Ton, Toff) (Max) | 45ns, 35ns |
| -3db Bandwidth | 120MHz |
| Charge Injection | -14pC |
| Channel Capacitance (CS(off), CD(off)) | 16pF, 42pF |
| Current - Leakage (IS(off)) (Max) | 5nA |
| Crosstalk | -90dB @ 1MHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 16-WFQFN |
| Supplier Device Package | 16-miniQFN (1.8x2.6) |
