MAX4617EEE
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MAX4617EEE |
|---|---|
| Manufacturer | Maxim Integrated |
| Description | 1 Circuit IC Switch 8:1 10 Ohm 16-QSOP |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| MAX4617EEE Price |  |
Technical Specifications of MAX4617EEE
| Datasheet |  MAX4617EEE datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Maxim Integrated |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | 8:1 |
| Number of Circuits | 1 |
| On-State Resistance (Max) | 10 Ohm |
| Channel-to-Channel Matching (ΔRon) | 200 mOhm |
| Voltage - Supply, Single (V+) | 2 V ~ 5.5 V |
| Voltage - Supply, Dual (V±) | - |
| Switch Time (Ton, Toff) (Max) | 15ns, 10ns |
| -3db Bandwidth | - |
| Charge Injection | 3pC |
| Channel Capacitance (CS(off), CD(off)) | 5pF, 27pF |
| Current - Leakage (IS(off)) (Max) | 1nA |
| Crosstalk | -96dB @ 100kHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 16-SSOP (0.154", 3.90mm Width) |
| Supplier Device Package | 16-QSOP |
