DG412HSDN-T1-E4
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | DG412HSDN-T1-E4 |
|---|---|
| Manufacturer | Vishay Siliconix |
| Description | 4 Circuit IC Switch 1:1 35 Ohm 16-QFN (4x4) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| DG412HSDN-T1-E4 Price |  |
Technical Specifications of DG412HSDN-T1-E4
| Datasheet |  DG412HSDN-T1-E4 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Vishay Siliconix |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Switch Circuit | SPST - NO |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Number of Circuits | 4 |
| On-State Resistance (Max) | 35 Ohm |
| Channel-to-Channel Matching (ΔRon) | - |
| Voltage - Supply, Single (V+) | 12V |
| Voltage - Supply, Dual (V±) | ±5 V ~ 20 V |
| Switch Time (Ton, Toff) (Max) | 105ns, 80ns |
| -3db Bandwidth | - |
| Charge Injection | 22pC |
| Channel Capacitance (CS(off), CD(off)) | 12pF, 12pF |
| Current - Leakage (IS(off)) (Max) | 250pA |
| Crosstalk | -88dB @ 1MHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 16-VQFN Exposed Pad |
| Supplier Device Package | 16-QFN (4x4) |
