TC7SBL384CFU,LF

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
Manufacturer Part Number | TC7SBL384CFU,LF |
---|---|
Manufacturer | Toshiba Semiconductor and Storage |
Description | 1 Circuit IC Switch 1:1 18 Ohm USV |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
TC7SBL384CFU,LF Price | ![]() |
Technical Specifications of TC7SBL384CFU,LF
Datasheet | ![]() |
---|---|
Category | Integrated Circuits (ICs) |
Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
Manufacturer | Toshiba Semiconductor and Storage |
Series | - |
Packaging | Cut Tape (CT) |
Part Status | Discontinued |
Switch Circuit | SPST - NO |
Multiplexer/Demultiplexer Circuit | 1:1 |
Number of Circuits | 1 |
On-State Resistance (Max) | 18 Ohm |
Channel-to-Channel Matching (ΔRon) | - |
Voltage - Supply, Single (V+) | 1.65 V ~ 3.6 V |
Voltage - Supply, Dual (V±) | - |
Switch Time (Ton, Toff) (Max) | 6ns, 6ns |
-3db Bandwidth | - |
Charge Injection | - |
Channel Capacitance (CS(off), CD(off)) | 3.5pF |
Current - Leakage (IS(off)) (Max) | 1μA |
Crosstalk | - |
Operating Temperature | -40°C ~ 85°C (TA) |
Package / Case | 5-TSSOP, SC-70-5, SOT-353 |
Supplier Device Package | USV |
