HEF4051BP,652
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | HEF4051BP,652 |
|---|---|
| Manufacturer | NXP Semiconductors |
| Description | 1 Circuit IC Switch 8:1 155 Ohm 16-DIP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| HEF4051BP,652 Price |  |
Technical Specifications of HEF4051BP,652
| Datasheet |  HEF4051BP,652 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | NXP Semiconductors |
| Series | - |
| Packaging | Tube |
| Part Status | Obsolete |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | 8:1 |
| Number of Circuits | 1 |
| On-State Resistance (Max) | 155 Ohm |
| Channel-to-Channel Matching (ΔRon) | 5 Ohm |
| Voltage - Supply, Single (V+) | 3 V ~ 15 V |
| Voltage - Supply, Dual (V±) | - |
| Switch Time (Ton, Toff) (Max) | - |
| -3db Bandwidth | 70MHz |
| Charge Injection | - |
| Channel Capacitance (CS(off), CD(off)) | 7.5pF |
| Current - Leakage (IS(off)) (Max) | 200nA |
| Crosstalk | -50dB @ 1MHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 16-DIP (0.300", 7.62mm) |
| Supplier Device Package | 16-DIP |
