MAX4565CPP+
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MAX4565CPP+ |
|---|---|
| Manufacturer | Maxim Integrated |
| Description | IC VIDEO SWITCH QUAD SPST 20DIP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MAX4565CPP+ Price |  |
Technical Specifications of MAX4565CPP+
| Datasheet |  MAX4565CPP+ datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches - Special Purpose |
| Manufacturer | Maxim Integrated |
| Series | - |
| Packaging | Tube |
| Part Status | Obsolete |
| Applications | Video |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Switch Circuit | SPST |
| Number of Channels | 4 |
| On-State Resistance (Max) | 60 Ohm |
| Voltage - Supply, Single (V+) | 2.7 V ~ 12 V |
| Voltage - Supply, Dual (V±) | ±2.7 V ~ 6 V |
| -3db Bandwidth | 350MHz |
| Features | Bi-Directional, T-Switch Configuration |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Package / Case | 20-DIP (0.300", 7.62mm) |
| Supplier Device Package | 20-PDIP |
