Technical Specifications of SN74HC175DT
| Datasheet |  SN74HC175DT datasheet |
|---|
| Category | Integrated Circuits (ICs) |
|---|
| Family | Logic - Flip Flops |
|---|
| Manufacturer | Texas Instruments |
|---|
| Series | 74HC |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Discontinued |
|---|
| Function | Master Reset |
|---|
| Type | D-Type |
|---|
| Output Type | Differential |
|---|
| Number of Elements | 1 |
|---|
| Number of Bits per Element | 4 |
|---|
| Frequency - Clock | 60MHz |
|---|
| Max Propagation Delay @ V, Max CL | 26ns @ 6V, 50pF |
|---|
| Trigger Type | Positive Edge |
|---|
| Current - Output High, Low | 5.2mA, 5.2mA |
|---|
| Voltage - Supply | 2 V ~ 6 V |
|---|
| Current - Quiescent | 8μA |
|---|
| Input Capacitance | 3pF |
|---|
| Operating Temperature | -40°C ~ 85°C (TA) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
|---|
We can supply Texas Instruments part# SN74HC175DT. Use the request quote form to request SN74HC175DT pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SN74HC175DT. The price and lead time for SN74HC175DT depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SN74HC175DT. We look forward to doing business with you.
