MC100EL04DTR2G
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MC100EL04DTR2G |
|---|---|
| Manufacturer | ON Semiconductor |
| Description | AND/NAND Gate Configurable 1 Circuit 2 Input 8-TSSOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MC100EL04DTR2G Price |  |
Technical Specifications of MC100EL04DTR2G
| Datasheet |  MC100EL04DTR2G datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Logic - Gates and Inverters - Multi-Function, Configurable |
| Manufacturer | ON Semiconductor |
| Series | 100EL |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Logic Type | AND/NAND Gate |
| Number of Circuits | 1 |
| Number of Inputs | 2 |
| Schmitt Trigger Input | No |
| Output Type | Differential |
| Current - Output High, Low | - |
| Voltage - Supply | 4.2 V ~ 5.7 V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
| Supplier Device Package | 8-TSSOP |
