74HC58N,652
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 74HC58N,652 |
|---|---|
| Manufacturer | NXP Semiconductors |
| Description | AND/OR Gate Configurable 2 Circuit 10 Input (3, 3, 2, 2) Input 14-DIP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 74HC58N,652 Price |  |
Technical Specifications of 74HC58N,652
| Category | Integrated Circuits (ICs) |
|---|---|
| Family | Logic - Gates and Inverters - Multi-Function, Configurable |
| Manufacturer | NXP Semiconductors |
| Series | 74HC |
| Packaging | Tube |
| Part Status | Obsolete |
| Logic Type | AND/OR Gate |
| Number of Circuits | 2 |
| Number of Inputs | 10 Input (3, 3, 2, 2) |
| Schmitt Trigger Input | No |
| Output Type | Single-Ended |
| Current - Output High, Low | - |
| Voltage - Supply | - |
| Operating Temperature | - |
| Mounting Type | Through Hole |
| Package / Case | 14-DIP (0.300", 7.62mm) |
| Supplier Device Package | 14-DIP |
