Technical Specifications of 74LVC1G14W5-7
| Datasheet |  74LVC1G14W5-7 datasheet |
|---|
| Category | Integrated Circuits (ICs) |
|---|
| Family | Logic - Gates and Inverters |
|---|
| Manufacturer | Diodes Incorporated |
|---|
| Series | 74LVC |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Logic Type | Inverter |
|---|
| Number of Circuits | 1 |
|---|
| Number of Inputs | 1 |
|---|
| Features | Schmitt Trigger |
|---|
| Voltage - Supply | 1.65 V ~ 5.5 V |
|---|
| Current - Quiescent (Max) | 200μA |
|---|
| Current - Output High, Low | 32mA, 32mA |
|---|
| Logic Level - Low | 0.3 V ~ 1.45 V |
|---|
| Logic Level - High | 1.2 V ~ 3.33 V |
|---|
| Max Propagation Delay @ V, Max CL | 5ns @ 5V, 50pF |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Supplier Device Package | SOT-25 |
|---|
| Package / Case | SC-74A, SOT-753 |
|---|
We can supply Diodes Incorporated part# 74LVC1G14W5-7. Use the request quote form to request 74LVC1G14W5-7 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 74LVC1G14W5-7. The price and lead time for 74LVC1G14W5-7 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 74LVC1G14W5-7. We look forward to doing business with you.
