Technical Specifications of SN7416NSR
| Datasheet |  SN7416NSR datasheet |
|---|
| Category | Integrated Circuits (ICs) |
|---|
| Family | Logic - Gates and Inverters |
|---|
| Manufacturer | Texas Instruments |
|---|
| Series | 7400 |
|---|
| Packaging | Cut Tape (CT) |
|---|
| Part Status | Active |
|---|
| Logic Type | Inverter |
|---|
| Number of Circuits | 6 |
|---|
| Number of Inputs | 6 |
|---|
| Features | Open Collector |
|---|
| Voltage - Supply | 4.75 V ~ 5.25 V |
|---|
| Current - Quiescent (Max) | - |
|---|
| Current - Output High, Low | -, 40mA |
|---|
| Logic Level - Low | 0.8V |
|---|
| Logic Level - High | 2V |
|---|
| Max Propagation Delay @ V, Max CL | 23ns @ 5V, 15pF |
|---|
| Operating Temperature | 0°C ~ 70°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Supplier Device Package | 14-SO |
|---|
| Package / Case | 14-SOIC (0.209", 5.30mm Width) |
|---|
We can supply Texas Instruments part# SN7416NSR. Use the request quote form to request SN7416NSR pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SN7416NSR. The price and lead time for SN7416NSR depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SN7416NSR. We look forward to doing business with you.
