74HC151PW-Q100,118
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 74HC151PW-Q100,118 |
|---|---|
| Manufacturer | NXP Semiconductors |
| Description | Multiplexer 1 x 8:1 16-TSSOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 74HC151PW-Q100,118 Price |  |
Technical Specifications of 74HC151PW-Q100,118
| Datasheet |  74HC151PW-Q100,118 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Logic - Signal Switches, Multiplexers, Decoders |
| Manufacturer | NXP Semiconductors |
| Series | 74HC |
| Packaging | Digi-Reel? |
| Part Status | Discontinued |
| Type | Multiplexer |
| Circuit | 1 x 8:1 |
| Independent Circuits | 1 |
| Current - Output High, Low | 5.2mA, 5.2mA |
| Voltage Supply Source | Single Supply |
| Voltage - Supply | 2 V ~ 6 V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 16-TSSOP |
