Technical Specifications of FAN7382MX
| Datasheet |  FAN7382MX datasheet |
|---|
| Category | Integrated Circuits (ICs) |
|---|
| Family | PMIC - Gate Drivers |
|---|
| Manufacturer | Fairchild Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Cut Tape (CT) |
|---|
| Part Status | Active |
|---|
| Driven Configuration | Half-Bridge |
|---|
| Channel Type | Independent |
|---|
| Number of Drivers | 2 |
|---|
| Gate Type | IGBT, N-Channel MOSFET |
|---|
| Voltage - Supply | 10 V ~ 20 V |
|---|
| Logic Voltage - VIL, VIH | 0.8V, 2.5V |
|---|
| Current - Peak Output (Source, Sink) | 350mA, 650mA |
|---|
| Input Type | Non-Inverting |
|---|
| High Side Voltage - Max (Bootstrap) | 600V |
|---|
| Rise / Fall Time (Typ) | 60ns, 30ns |
|---|
| Operating Temperature | -40°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
|---|
| Supplier Device Package | 8-SOIC |
|---|
We can supply Fairchild Semiconductor part# FAN7382MX. Use the request quote form to request FAN7382MX pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number FAN7382MX. The price and lead time for FAN7382MX depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# FAN7382MX. We look forward to doing business with you.
