Technical Specifications of NCP5009DMR2
| Category | Integrated Circuits (ICs) |
|---|
| Family | PMIC - LED Drivers |
|---|
| Manufacturer | ON Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Obsolete |
|---|
| Type | DC DC Regulator |
|---|
| Topology | Step-Up (Boost) |
|---|
| Internal Switch(s) | Yes |
|---|
| Number of Outputs | 1 |
|---|
| Voltage - Supply (Min) | 2.7V |
|---|
| Voltage - Supply (Max) | 6V |
|---|
| Voltage - Output | 15V |
|---|
| Current - Output / Channel | 75mA |
|---|
| Frequency | 5MHz |
|---|
| Dimming | - |
|---|
| Applications | Backlight |
|---|
| Operating Temperature | -25°C ~ 85°C (TA) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) |
|---|
| Supplier Device Package | 10-Micro |
|---|
We can supply ON Semiconductor part# NCP5009DMR2. Use the request quote form to request NCP5009DMR2 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number NCP5009DMR2. The price and lead time for NCP5009DMR2 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# NCP5009DMR2. We look forward to doing business with you.
