DS3991Z+T&R/PPV

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
Manufacturer Part Number | DS3991Z+T&R/PPV |
---|---|
Manufacturer | Maxim Integrated |
Description | IC CTRLR CCFL PUSH-PULL 16-SOIC |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
DS3991Z+T&R/PPV Price | ![]() |
Technical Specifications of DS3991Z+T&R/PPV
Datasheet | ![]() |
---|---|
Category | Integrated Circuits (ICs) |
Family | PMIC - Lighting, Ballast Controllers |
Manufacturer | Maxim Integrated |
Series | - |
Packaging | Tape & Reel (TR) |
Part Status | Discontinued |
Type | CCFL Controller |
Frequency | 40kHz ~ 80kHz |
Voltage - Supply | 4.5 V ~ 5.5 V |
Current - Supply | 5mA |
Current - Output Source/Sink | - |
Dimming | Yes |
Operating Temperature | -40°C ~ 85°C |
Mounting Type | Surface Mount |
Package / Case | 16-SOIC (0.154", 3.90mm Width) |
Drawing Number | 175; 21-0041; SE; 16 |
Mfr Reel Diameter | 13" (330mm) |
Mfr Reel Tape Material | Plastic |
Mfr Reel Tape Width | 16mm |
Supplier Device Package | 16-SOIC |
