TPS2H160BQPWPRQ1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TPS2H160BQPWPRQ1 |
|---|---|
| Manufacturer | Texas Instruments |
| Description | IC PWR SWITCH N-CH 1:1 16HTSSOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| TPS2H160BQPWPRQ1 Price |  |
Technical Specifications of TPS2H160BQPWPRQ1
| Datasheet |  TPS2H160BQPWPRQ1 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | PMIC - Power Distribution Switches, Load Drivers |
| Manufacturer | Texas Instruments |
| Series | Automotive, AEC-Q100 |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Switch Type | General Purpose |
| Number of Outputs | 2 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | On/Off |
| Voltage - Load | 3.4 V ~ 40 V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 2.5A |
| Rds On (Typ) | 155 mOhm |
| Input Type | - |
| Features | - |
| Fault Protection | Current Limiting (Adjustable), Over Temperature |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) Exposed Pad |
| Supplier Device Package | 16-HTSSOP |
