TPS22963CYZPT
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TPS22963CYZPT |
|---|---|
| Manufacturer | Texas Instruments |
| Description | IC LOAD SWITCH ULTRA LOW 6-DSBGA |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| TPS22963CYZPT Price |  |
Technical Specifications of TPS22963CYZPT
| Datasheet |  TPS22963CYZPT datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | PMIC - Power Distribution Switches, Load Drivers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Switch Type | General Purpose |
| Number of Outputs | 1 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | On/Off |
| Voltage - Load | 1 V ~ 5.5 V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 3A |
| Rds On (Typ) | 13.3 mOhm |
| Input Type | Non-Inverting |
| Features | Slew Rate Controlled |
| Fault Protection | Reverse Current |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 6-XFBGA, DSBGA |
| Supplier Device Package | 6-DSBGA |
