Technical Specifications of LCDX1/0-12-X
| Datasheet |  LCDX1/0-12-X datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminals - Rectangular Connectors |
|---|
| Manufacturer | Panduit Corp |
|---|
| Series | Pan-Lug? |
|---|
| Packaging | Bulk |
|---|
| Terminal Type | Rectangular Tongue |
|---|
| Stud/Tab Size | 1/2 Stud |
|---|
| Terminal Style | Two Stud Holes |
|---|
| Tab Thickness | 0.130" (3.30mm) |
|---|
| Length - Overall | 4.040" (102.62mm) |
|---|
| Width - Outer Edges | 0.850" (21.59mm) |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp, Barrel |
|---|
| Wire Gauge | 1/0 AWG |
|---|
| Insulation | Non-Insulated |
|---|
| Features | - |
|---|
| Color | Pink |
|---|
| Contact Finish | Electro-Tin |
|---|
| Contact Material | Copper |
|---|
| Diameter - Barrel ID | 0.450" (11.43mm) |
|---|
| Diameter - Barrel OD | 0.580" (14.73mm) |
|---|
| Diameter - Ring ID | 0.530" (13.46mm) |
|---|
We can supply Panduit Corp part# LCDX1/0-12-X. Use the request quote form to request LCDX1/0-12-X pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number LCDX1/0-12-X. The price and lead time for LCDX1/0-12-X depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# LCDX1/0-12-X. We look forward to doing business with you.
