TPC8012-H(TE12L,Q)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
Manufacturer Part Number | TPC8012-H(TE12L,Q) |
---|---|
Manufacturer | Toshiba Semiconductor and Storage |
Description | MOSFET N-CH 200V 1.8A 8-SOP |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
TPC8012-H(TE12L,Q) Price | ![]() |
Technical Specifications of TPC8012-H(TE12L,Q)
Datasheet | ![]() |
---|---|
Category | Discrete Semiconductor Products |
Family | Transistors - FETs, MOSFETs - Single |
Manufacturer | Toshiba Semiconductor and Storage |
Series | - |
Packaging | Digi-Reel? |
FET Type | MOSFET N-Channel, Metal Oxide |
FET Feature | Standard |
Drain to Source Voltage (Vdss) | 200V |
Current - Continuous Drain (Id) @ 25°C | 1.8A (Ta) |
Rds On (Max) @ Id, Vgs | 400 mOhm @ 900mA, 10V |
Vgs(th) (Max) @ Id | 5V @ 1mA |
Gate Charge (Qg) @ Vgs | 11nC @ 10V |
Input Capacitance (Ciss) @ Vds | 440pF @ 10V |
Power - Max | - |
Operating Temperature | 150°C (TJ) |
Mounting Type | Surface Mount |
Package / Case | 8-SOIC (0.173", 4.40mm Width) |
Supplier Device Package | 8-SOP (5.5x6.0) |
